    SDM30G60FC is a 3-phase brushless DC motor driver with high integration and high reliability for low power inverter driving such as air conditioner, refrigerator and dishwasher. It has embedded six low-loss IGBTs and 3-phase full-bridge gate drivers with high voltage.

    The under voltage and short circuit protections integrated make the circuit work safely in a wide range. The current of each phase can be detected separately because there is one independent negative DC terminal for each phase.

    SDM30G60FC uses high-insulation design, compact package and carries heat easily, which makes it easy to use especially for compact installation applications.

Main feature
  • Built-in low-loss 600V/30A IGBT;

  • Built-in high-voltage integrated circuit of gate driver;

  • Built-in under voltage protection, over current protection and temperature output;

  • Built-in bootstrap diode with current limiting resistor;

  • Compatible with 3.3V, 5V  MCU interface, active high;

  • Three independent negative DC terminal for inverter current detection;

  • Alarm signal: for low-side under voltage, over temperature and short circuit protections;

  • Very low thermal resistance using Al2O3 DBC substrate;

  • Insulation level: 1500Vrms/min

Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDM30G60FC DIP-24HL SDM30G60FC Halogen free Tube
Block Diagram
